PCR-BPF
Parameters | SPEC | 图例/Example |
Transmission Band | TAvg>95%@820~830nm | 98.36% |
TMax-TMin<3%@825±4nm | 1.55% | |
Center Wavelength | 825±2nm | 824.7 |
Bandwidth(nm) | 15±1.5nm | 15.5 |
Blocking Band 1 | ODAvg>3@300~812nm | Pass |
Blocking Band 2 | ODAvg>3@838~1000nm | Pass |
Angle of Incidence | 3 ± 2 degree | |
Cone Half-angle | 3.5 degree |
